Ruida RDC6585PC-DFM-RD Single Track Large Visual Spray Cutting Controller

Name: Ruida RDC6585PC-DFM-RD Single Track Large Visual Spray Cutting Controller
Brand: Shenzhen Ruida Technology Co., Ltd.
SKU: RDC6585PC-DFM-RD
Price: 410.00 USD
Availability: InStock

Brand Name:	Ruida
Model Number:	RDC6585PC-DFM-RD
MOQ:	1
Price:	Negotiable, contact us
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, FCC, RoHS

Laser:

CO2 Glass Tube And CO2 RF Tube

Nozzle:

Support Solenoid Valve And Piezoelectric Valve

Axis:

Eight

Laser Channel:

Two

Spray Adhesive Channel:

Two

Double Head Synchronous:

Support

Communication Interface:

Ethernet, USB

Panel:

5'' Color Screen + Keys

Feeding:

U Axis Feeding/ Y And U Axes Feeding Synchronously, Ordinary Feeding, Ultra-wide Segmentation Feeding

Double Coordinate System Processing:

Not Support

Glue Spray Process:

Support The Adjustment Of Position And Amount Of Glue Spray, Delay Process Control

Model:

Large-format Panoramic Visual Positioning And Egde Extraction Function

Packaging Details:

Carton

Highlight:

Ruida RDC6585PC-DFM-RD

Large Visual Spray Cutting Controllers

Single Track Spray Cutting Controller

Product Description

Ruida Controller RDC6585PC-DFM-RD Single-track Large Visual Spray Cutting Integrated Controller

Description Of Ruida Controller RDC6585PC-DFM-RD
The RDC6585PC-DFM-RD system is a new generation of integrated spray-cut control system developed by Ruida Technology. The human-machine operating system based on a 5-inch color screen has a more user-friendly interface and more powerful functions. The controller has a complete and excellent motion control function, which can realize laser processing and glue spraying processing separately by layers. The control system has multiple general/special IO control interfaces and multiple peripheral interconnection interfaces. The controller can be used for single-channel laser + glue spraying processing, and can also be used to drive single/multi-belt double-head inter-moving models. It can realize two-channel laser inter-moving processing and two-channel glue inter-moving processing by layers at most.

Parameter	RDC6585PC-DFM-RD
Laser	CO2 glass tube and CO2 RF tube
Nozzle	Support solenoid valve and piezoelectric valve
Axis	Eight
Laser channel	Two
Spray adhesive channel	Two
Double head synchronous	Support
Communication interface	Ethernet, USB
Panel	5” color screen + keys
Feeding	U axis feeding/ Y and U axes feeding synchronously, ordinary feeding, ultra-wide segmentation feeding
Double coordinate system processing	Not support
Cutting	Support
Glue spray process	Support the adjustment of position and amount of glue spray, delay process control
Model	Large-format panoramic visual positioning and egde extraction function
Installment encryption	Support
Onboard clock	Not support
Firmware upgrade	Remote upgrade of panel and mainboard program
Software	RDWorksV8
Size	Panel: L180mmW140mmH42.1mm Mainboard: L211.5mmW134mmH33mm
Language	12 languages including simplified Chinese, traditional Chinese, English, French, Russian, Portuguese, Turkish, German, Spanish, Vietnamese, Korean, and Italian
Accessories	Wireless handheld box, RD-APP and RD-WIFI

Key Function
(1)Precise PPI control mode.
(2)Realize and finish laser cutting and glue spray through different layers at the same time.
(3)Support large-format panoramic visual positioning and double heads asynchronous processing.

Ruida RDC6585PC-DFM-RD Single Track Large Visual Spray Cutting Controller 0

Application area

Suitable for glue spray, dispensing, drawing lines and laser cutting in clothing, leather, toys,shoes and 3C industries

Ruida RDC6585PC-DFM-RD Single Track Large Visual Spray Cutting Controller 1

Software

RDWorksV8(Free)+RDVisionWorks

Ruida RDC6585PC-DFM-RD Single Track Large Visual Spray Cutting Controller 2

Product Certification
