| Brand Name: | Ruida |
| Model Number: | RDM4024G-PCI |
| MOQ: | 1 |
| Price: | Negotiable, contact us |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Attribute | Value |
|---|---|
| Laser Source | CO2, fiber and UV |
| Axes control | Pulse+dir or +/-pulse, differential double-ended output |
| Communication Interface | PCI |
| Galvanometer protocol | XY2-100 |
| Input/output | 6 channels input/output |
| Installment Encryption | Support |
| Firmware Upgrade | Remote upgrade of mainboard program |
| APP | Mantisolo, operating system: Android 8.0 or above, IOS 12.0 or above |
| Software | LaserMark |
| Language | Chinese and English |
| Axes | 4 motion axes + 2 galvanometer shafts |
| Axis control interface | Pulse + dir or +/- pulse, differential two-terminal output |
| System Function | Ordinary marking |
| Operating system | WinXP, Win7, Win8, Win10, 32-bit or 64-bit |
Ruida Laser Controller RDM4024G-PCI Standard Marking Card Laser Marking Control System
The RDM4024G-PCI marking control card is a high-performance motion controller developed by Ruida Technology, specifically for laser galvanometer applications. It adheres to standard PCI specifications and is built on an industrial-grade DSP + FPGA architecture. This design integrates advanced galvanometer control algorithms with laser synchronous control algorithms, enabling precise trajectory management of the galvanometer. Additionally, the card employs bi-directional DMA operations to enhance data communication efficiency.
| Parameter | Specification |
|---|---|
| Laser source | CO2, fiber and UV |
| Axis | Four motion axes + two galvanometer shafts |
| Communication | PCI |
| Axis control interface | Pulse + dir or +/- pulse, differential two-terminal output |
| System function | Ordinary marking |
| Software | LaserMark |
| Installment encryption | Support |
| Firmware upgrade | Remote upgrade of mainboard program |
| Operating system | Win7, Win8, Win10, 32-bit or 64-bit |
| Language | Chinese and English |
LaserMark
